Magnetic Particle Inspection or Magnaflux as it is sometimes called uses magnetic leakage fields to detect surface and subsurface cracks and discontinuities. Magnetic particle testing is done by inducing a magnetic field in a ferromagnetic material and dusting the surface with iron particles (either dry or suspended in a liquid). Surface imperfections will distort the magnetic field and concentrate the iron particles near imperfections, thus indicating their presence. Magnetic particle testing can be brought to your facility or can be performed in our facility, depending upon your application and time frame.

NDT Specialists performs Magnetic Particle testing on over 1 million pieces annually. This includes casting under a square inch weighing less than a few ounces to welds on tanks weighing a over a few tons. MT testing is a very popular way to test a variety a pieces that have complex shapes and sizes at minimal costs.

MT Equipment:

  • 2 - 6' Horizontal Magnetic Particle Benches
  • 1 - 8' Horizontal Magnetic Particle Bench
  • Multiple Yokes/Black Lights
  • Dry/Wet MT Equipment
  • Level III Services
